v 2.3 — September 2015 Altanium Delta3
122 Power Limiting
10.1.10 Power Limiting
Power Limiting is used to control the maximum output power delivered to each zone. The
output power limit for each zone can be set from 0% to the Global Output Power Limit value.
If the Global Output Power Limit value is adjusted lower than the zone setting then the
power limit for each zone is automatically trimmed by the system to not exceed the global
value.
1. On the System Setup screen, under Power Limiting, touch the Global Output Power
Limit field.
2. Enter the desired limit.
3. Touch the Accept button.
Table 10-6 Power Deviation Settings
Setting Description
Power Deviation Enable Toggles the feature on or off.
Sample Period Defines the amount of time the system will take
to establish a baseline average power value (i.e.
learn the mold). The default value is 2 minutes
and the range is from 1 to 10 minutes.
Stabilization Time Defines the amount of time the system will take,
after all active zones have reached setpoint,
before it will initiate the Sample (learning)
Period. The default value is 2 minutes and the
range is from 1 to 10 minutes.
Deviation Limit Field This field is used by the system to determine the
tolerance value that will be used for declaring an
error. This value will only be used if the value
calculated by the system cannot be used. The
default value is 10% and the range is from 1 to
100% definable in 1% increments. This field is
not accessible unless the user logs in and sets
the controller function to true in the User
Profiles screen and enables security.
Baseline Average Relearn Button This button is used to start a new sample period
in cases where the original sample time was not
sufficient to establish good baseline average
power values. This button is a manual override
that should only be active after all active zones
have reached setpoint and the Stabilization
Time has expired.
Baseline Established Status Field This field is used to determine if a baseline has
already been done for the currently loaded mold
setup.
