Frequently Used Fields 67
User Guide v 2.3 — September 2015 Making Adjustments
7.5.1 Frequently Used Fields
7.5.2 Zone Edit Fields
Item Description
Temperature Setpoint Touch this field to display a keypad for adjusting a zone(s) setpoint in
Auto or Monitor regulation.
Power Setpoint Touch this field to display a keypad for adjusting the percentage of
power output when a zone(s) is in Manual regulation.
Zone On/Off Touch this field to turn the selected zone ON or OFF. A dialog appears and
allows the user to choose a value. The default is ON.
Regulation Mode This setting allows users to set the regulation mode for the selected zone.
AUTO or Automatic (closed loop) means the system will use a
thermocouple to control the temperature. MAN or Manual (open loop)
means the system will only apply power (0 to 100%) to the heater and not
look for thermocouple feedback. MON or Monitor means the system will
only monitor the temperature of a thermocouple (no power output).
Alarm Window Touch this field to display a keypad for adjusting the upper and lower
alarm limits.
Abort Window Touch this field to display a keypad for adjusting the upper and lower
abort limits.
Item Description
Zone Name Touch this field to display a keyboard for assigning a custom name to a
zone or group of zones.
Group Name Touch this field to define a name for a group of selected zones. All zones
assigned a group name are used to create group views in the Multi Group
View as well as create a Shortcut Icon button in the Shortcut section on
the Home screen.
Zone Locked/Unlocked Touch this field to display a dialog to lock or unlock zone(s). If a zone(s) is
locked, it will prevent any changes from being made to it from the Quick
Set screen.
Display/Hide Zone Touch this field to display a dialog to display or hide a zone(s). If hide is
selected, the zone(s) will be removed from all the Zone Data View
screens.
