v Schedule Name (schedule name)
v Last replicated Snapshot Time (yyyy-mm-dd hh:mm:ss)
v Specified RPO (value in h:mm:ss format)
The following deactivation reasons can be read from the output list (available only
in XML output format):
v INACTIVE_USER - No_Error
v INACTIVE_SECONDARY_LOCKED - Secondary_Pool_Exhausted
v INACTIVE_POOL_EXHAUSTED - Master_Pool_Exhausted
v INACTIVE_VOL_SIZE_MISMATCH -
Remote_And_Local_Volume_Size_Mismatch
v INACTIVE_CONS_GROUP_MEMBERSHIP_MISMATCH -
Cons_Group_Membership_Mismatch
v INACTIVE_POSSIBLE_VOL_SIZE_MISMATCH -
Possible_Remote_And_Local_Volume_Size_Mismatch
v INACTIVE_POSSIBLE_CONS_GROUP_MEMBERSHIP_MISMATCH -
Possible_Cons_Group_Membership_Mismatch
v INACTIVE_THIN_PROVISIONING - No_Thin_Provisioning_Resources
v INACTIVE_PEER_STATUS_MISMATCH - Peer_Status_Mismatch
v INACTIVE_UPGRADE - Temporarily_Deactivated_For_Upgrade
Id Name Description Default Position
local_peer_
name
Name N/A 1
mirror_object Mirror Object N/A 3
designation Designation N/A N/A
current_role Role N/A 4
target_name Remote System N/A 5
remote_peer_
name
Remote Peer N/A 6
active Active N/A 7
sync_state Status N/A 8
connected Link Up N/A 9
size_to_
synchronize
Size To Sync (MB) N/A N/A
operational Operational N/A N/A
sync_progress Sync Progress (%) N/A N/A
mirror_error Mirror Error No Error, Secondary
pool exhausted,
Configuration error or
No thin provisioning
resources
N/A
sync_type Mirror Type N/A 2
schedule_name Schedule Name N/A N/A
last_
replicated_
snapshot_time
Last Replicated N/A N/A
224 IBM XIV Storage System User Manual

IBM XIV Specifications

General

Power Supply	Redundant power supplies
Drive Type	SATA
Redundancy	Fully redundant components
Connectivity	Fibre Channel, iSCSI
Form Factor	Rack-mounted
Cache	Distributed cache across modules
Data Protection	Snapshots, remote mirroring
Performance	High throughput and low latency
Scalability	Modular, scale-out architecture
Cooling	Redundant cooling
Architecture	Grid-based, distributed architecture
