Component ID Status Currently Functioning Model L1 Input OK L2 Input OK
-------------- -------- ----------------------- --------- ------------- -------------
1:ATS:1 OK yes ATS-60A no yes
Cont.:
Outlet 1 State Outlet 2 State Outlet 3 State Firmware Version
---------------- ---------------- ---------------- ------------------
J2 J2 J2 4
Cont.:
3-Phase Dual Active
--------- -------------
no no
Id Name Default Position
component_id Component ID 1
status Status 2
currently_
functioning
Currently Functioning 3
model Model 4
input_l1 L1 Input OK 5
input_l2 L2 Input OK 6
out1_state Outlet 1 State 7
out2_state Outlet 2 State 8
out3_state Outlet 3 State 9
firmware_
version
Firmware Version 10
three_phase_
type
3-Phase 11
dual_active_
type
Dual Active 12
coil_l1 Coil A On N/A
coil_l2 Coil B On N/A
pickup_l1 A Pick-Up N/A
pickup_l2 B Pick-Up N/A
default_cal Default Calibration N/A
serial_control Serial Control N/A
logic_power Logic Power N/A
output_30A_1 Output 30A #1 N/A
output_30A_2 Output 30A #2 N/A
output_30A_3 Output 30A #3 N/A
output_10A Output 10A N/A
ats_reply_
errors
ATS Reply Errors N/A
Chapter 20. Hardware Maintenance
403
