Parameters:
Name Description Mandatory Default
module Limits the listing to a
specific module.
N All DIMMs in all
modules.
dimm Lists only a specific
DIMM.
N A specific DIMM.
This command lists the DIMMs in the XIV system.
Example:
dimm_list -f all
Output:
Component ID Status Currently Functioning Hardware Status DIMM Id CPU
-------------- -------- ----------------------- ----------------- --------- -----
1:DIMM:10:1 OK yes OK 2 0
1:DIMM:10:2 OK yes OK 4 0
1:DIMM:10:3 OK yes OK 6 0
1:DIMM:11:1 OK yes OK 2 0
1:DIMM:11:2 OK yes OK 4 0
1:DIMM:11:3 OK yes OK 6 0
Cont.:
Channel Slot Size(Mb) Speed(MHz) Manufacturer Serial Original Serial
--------- ------ ---------- ------------ -------------- ---------- -----------------
0 0 8192 1333 Samsung 50F84144 50F84144
1 0 8192 1333 Samsung 59F84144 59F84144
2 0 8192 1333 Samsung FAF74144 FAF74144
0 0 8192 1333 Samsung 4AF84144 4AF84144
1 0 8192 1333 Samsung A1F74144 A1F74144
2 0 8192 1333 Samsung 90F74144 90F74144
Cont.:
Part # Original Part Number Requires Service
------------------ ---------------------- ------------------
M393B1K70CH0-YH9 M393B1K70CH0-YH9
M393B1K70CH0-YH9 M393B1K70CH0-YH9
M393B1K70CH0-YH9 M393B1K70CH0-YH9
M393B1K70CH0-YH9 M393B1K70CH0-YH9
M393B1K70CH0-YH9 M393B1K70CH0-YH9
M393B1K70CH0-YH9 M393B1K70CH0-YH9
Id Name Default Position
component_id Component ID 1
status Status 2
currently_
functioning
Currently Functioning 3
hardware_
status
Hardware Status 4
dimm_id DIMM Id N/A
cpu CPU N/A
channel Channel N/A
424 IBM XIV Storage System User Manual
