17-19 Operators’ Manual
990400 Rev C 2010 May 1
11-6
To reposition the phantom right or left on the Preview screen,
use the Back / Front feature.
21. When the BB Phantom is centered and level, click the Calibrate
button on the Geometry panel (bottom).
22. Select both the Landscape and Portrait calibration modes.
The X-ray device may be dangerous to the Patient and operator if
you do not observe and follow the operating instructions. Do not
operate this system unless you have received training to perform a
procedure.
23. Click OK to start the X-ray exposure.
24. On the Control Box, press Scan when prompted. An audible
alarm is sounded and the X-ray ON light is illuminated during
radiation exposure.
