Intel® Server System S7000FC4UR TPS BIOS User Interface
Revision 1.0
165
Table 48. Setup Utility — Memory Riser Board Information Screen Fields
Setup Item Options Help Text Comments
DIMM_#
<Current
DIMM State>
Information only
Displays the state of each DIMM socket present on the
board. Each DIMM socket field reflects one of the
following possible states:
Installed: There is a FBDIMM installed in this slot.
Not Installed: No FBDIMM is installed in this slot.
Disabled: The FBDIMM installed in this slot has
been disabled by the BIOS in order to optimize
memory configuration.
Failed: The FBDIMM installed in this slot is faulty or
malfunctioning.
Spare Unit: The FBDIMM is functioning as a spare
unit for Memory RAS purposes.
15.2.3.3.3 Mass Storage Controller Configuration Screen
The Mass Storage Controller Configuration screen provides configuration options and
informational for Serial Attached SCSI (SAS) and Serial ATA (SATA) devices.
From the Main screen select Advanced | Mass Storage Controller Configuration to access this
screen.
Advanced
Mass Storage Controller Configuration
AHCI Option ROM Enabled / Disabled
SAS Option ROM Enabled / Disabled
SATA Mode IDE / AHCI / SW RAID
► SATA Port 0 < Not Installed / Drive Information >
► SATA Port 1 < Not Installed / Drive Information >
► SATA Port 2 < Not Installed / Drive Information >
► SATA Port 3 < Not Installed / Drive Information >
► SATA Port 4 < Not Installed / Drive Information >
► SATA Port 5 < Not Installed / Drive Information >
Figure 51. Setup Utility — Mass Storage Controller Configuration Screen Display
