Intel S7000FC4UR Technical Product Specification

BIOS User Interface ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
174
15.2.3.3.7 LAN Configuration Screen
The LAN Configuration screen provides configuration options for LAN controllers on the main
board and I/O riser board.
From the Main screen select Advanced | LAN Configuration to access this screen.
Advanced
LAN Configuration
Intel
®
I/OAT
Enabled / Disabled
Onboard NIC 1 ROM Enabled / Disabled
Onboard NIC 2 ROM Enabled / Disabled
Onboard NIC iSCSI ROM Enabled / Disabled
Onboard NIC1 MAC Address <MAC Address>
Onboard NIC2 MAC Address <MAC Address>
I/O Riser Board NIC ROM Enabled / Disabled
I/O Riser Board NIC1 Enabled / Disabled
I/O Riser Board NIC2 Enabled / Disabled
I/O Riser Board NIC1 MAC Address <MAC Address>
I/O Riser Board NIC2 MAC Address <MAC Address>
Figure 55. Setup Utility — LAN Configuration Screen Display
Table 53. Setup Utility — LAN Configuration Screen Fields
Setup Item Options Help Text Comments
Intel
®
I/OAT
Enabled
Disabled
Intel
®
I/O Acceleration
Technology (Intel
®
I/OAT)
accelerates TCP/IP
processing for onboard
NICs, delivers data-
movement efficiencies
across the entire server
platform, and minimizes
system overhead.
