BIOS Error Handling ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
238
Progress Code Progress Code Definition
Runtime Phase / EFI Operating System Boot
0xF4 Entering sleep state
0xF5 Exiting sleep state
0xF8 Operating system has requested EFI to close boot services
ExitBootServices ( ) has been called
0xF9 Operating system has switched to virtual address mode
SetVirtualAddressMap ( ) has been called
0xFA Operating system has requested the system to reset
ResetSystem () has been called
Pre-EFI Initialization Module (PEIM) / Recovery
0x30 Crisis recovery has been initiated because of a user request
0x31 Crisis recovery has been initiated by software (corrupt flash)
0x34 Loading crisis recovery capsule
0x35 Handing off control to the crisis recovery capsule
0x3F Unable to complete crisis recovery.
19.3.3 POST Error Manager Messages and Handling
The POST Error Manager displays error messages reported by the system BIOS during POST.
The system BIOS truncates the 32-bit EFI POST Progress Code associated with the error to 16-
bit values for display in the POST Error Manager.
The POST Error Manager behavior in response to the error is defined by the error severity
reported by the BIOS. Errors are categorized in one of three severity levels. The system
behavior in response to severity level of fatal, major, or minor
19.3.3.1 Fatal
The system behavior in response to fatal error is described below:
BIOS logs an error to the POST Error Manager.
BIOS logs an error message to the BMC System Event Log (SEL).
BIOS unconditionally enters POST Error Manager to display error message.
BIOS halts the system to prevent boot.
The user needs to replace the faulty part and restart the system.
19.3.3.2 Major
The system behavior in response to major error is described below:
BIOS logs an error to the POST Error Manager.
BIOS logs an error message to the BMC System Event Log (SEL).
