Intel® Server System S7000FC4UR HSC IPMB Application and Sensors
Revision 1.0
309
30.2.1 Digital and Discrete Sensor Formats
Drive slot sensors have unique, device-specific formats.
Table 111. Sensor Formats
Sensor Name Sensor # Format (2-bytes)
Drive Slot Status 02h-09h Bit 15:13: Reserved.
Bit 12: Identify asserted.
Bit 11: Prepared for Operation.
Bit 10: Ready for Insertion/Removal.
Bit 09: Device Inserted.
Bit 08: Rebuild stopped.
Bit 07: Hot Spare.
Bit 06: Un-configured.
Bit 05: Predicted Fault.
Bit 04: Parity Check.
Bit 03: In Critical Array.
Bit 02: In Failed Array.
Bit 01: Device Rebuilding.
Bit 00: Device Faulty.
Drive Slot Presence 0Ah-11h Bit 15:2: Reserved
Bit 01: Device Inserted/Device Present
Bit 00: Device Removed/Device Absent.
30.3 Event Message Generation
Specified sensor events that are detected by the HSC cause a corresponding event message to
be sent out on the IPMB. Event message generation is configured via IPMI commands. The
format for event messages is in the Intelligent Platform Management Interface Specification.
