Intel® Server System S7000FC4UR TPS System Overview
Revision 1.0
75
8.5 Specifications
8.5.1 Environmental Specifications
The production system will be tested to the environmental specifications as indicated in Table
19.
Table 19. Environmental Specifications Summary
Environment Specification
Temperature operating 10°C to 35°C (50°F to 95°F)
Temperature non-operating -40°C to 70°C (-40°F to 158°F)
Altitude -30 to 1,500 m (-100 to 5,000 ft)
Humidity non-operating 95%, non-condensing at temperatures of 25°C (77°F) to 30°C (86°F)
Vibration non-operating 2.2 Grms, 10 minutes per axis on each of the three axes
Shock operating Half-sine 2 G, 11 ms pulse, 100 pulses in each direction, on each of the
three axes
Shock non-operating Trapezoidal, 25 G, two drops on each of six faces
V : 175 inches/sec on bottom face drop, 90 inches/sec on other 5 faces
Safety UL60 950, CSA60 950, AS/NZS 3562, GB4943-1995, EN60 950 and
73/23/EEC, IEC 60 950, EMKO-TSE (74-SEC) 207/94, GOST-R 50377-
92
Emissions Certified to FCC Class A; tested to CISPR 22 Class A, EN 55022 Class
A and 89/336/EEC, VCCI Class A, AS/NZS 3548 Class A, ICES-003
Class A, GB9254-1998, MIC Notice 1997-42 Class A, GOST-R 29216-
91 Class A, BSMI CNS13438
Immunity Verified to comply with EN55024, CISPR 24, GB9254-1998, MIC Notice
1997-41, GOST-R 50628-95
Electrostatic discharge Tested to ESD levels up to 15 kilovolts (kV) air discharge and up to 8 kV
contact discharge without physical damage
Acoustic Sound power: < 7.0 BA at ambient temperature < 23° C measured
using the Dome Method
GOST MSanPiN 001-96
8.5.2 Physical Specifications
Table 20 describes the physical specifications of the system.
Table 20. Physical Specifications
Specification Value
Height 6.8 inches (173 mm)
Width 17.6 inches (447 mm)
Depth 27.8 inches (706 mm)
Front clearance 3 inches (76 mm)
Side clearance 1 inch (25 mm)
Rear clearance 6 inches (152 mm)
