15.2.3.3.4 Serial Port Configuration Screen
The Serial Port Configuration screen provides configuration options for Serial Port A and Serial
Port B.
From the Main screen select Advanced | Serial Port Configuration to access this screen.
Advanced
Serial Port Configuration
Serial A Enable Enabled / Disabled
Address 3F8h / 2F8h / 3E8h / 2E8h
IRQ 3 / 4
Serial B Enable Enabled / Disabled
Address 3F8h / 2F8h / 3E8h / 2E8h
IRQ 3 / 4
Figure 52. Setup Utility — Serial Port Configuration Screen Display
Table 50. Setup Utility — Serial Ports Configuration Screen Fields
Setup Item Options Help Text Comments
Serial A Enable
Enabled
Disabled
Enable or Disable serial port A.
Address
3F8h
2F8h
3E8h
2E8h
Select serial port A base I/O
address.
IRQ 3
4
Select serial port A interrupt
request (IRQ) line.
Serial B Enable
Enabled
Disabled
Enable or Disable serial port B. Serial B is no longer available as a serial port
when SOL or EMP mode are in effect.
Address 3F8h
2F8h
3E8h
2E8h
Select serial port B base I/O
address.
IRQ
3
4
Select serial port B interrupt
request (IRQ) line.
