Intel S7000FC4UR Technical Product Specification

BIOS Error Handling ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
232
Table 87. SEL Entry Format — System Firmware Progress Sensor Type Examples
Error Type Event Data 1 Event Data 2 Event Data 3
POST Error Code 8190h 0xA0 0x90 0x81
19.2.6 IPMI Sensor Type Events — Event Logging Disabled
The BIOS logs SEL entries for the following events according to the format described in the
table below:
 Sensor Offset 00h — Correctable Memory Error Logging Disabled
Note: SEL record logging for ALL other Event Logging Disabled Sensor Offsets is the
responsibility of the BMC (i.e. BIOS is not responsible for SEL records indicating SEL Full or
Log Area Reset/Cleared).
See the Intelligent Platform Management Interface Specification, Version 2.0, Table 42-3 for the
following implementation details:
Table 88. SEL Entry Format — Event Logging Disabled Sensor Type
Byte Field IPMI Description BIOS Implementation
11 Sensor Type See the Intelligent Platform Management
Interface Specification, Version 2.0, Table
42-3 for allowable values.
The BIOS sends this to the BMC:
 0x10 = Event Logging Disabled
12 Sensor
Number
Number of sensor that generated this
event.
The BIOS sends this to the BMC:
 0x08 = Correctable Memory Error
Logging Disabled
14 Event Data 1
(ED1)
Bit [7:6]
 00b = ED2 unspecified
 10b = ED2 contains OEM value
Bit [5:4]
 00b = ED3 unspecified
 10b = ED3 contains OEM value (The
BIOS does not use encodings 01b or
11b for errors discussed in this
document.).
Bit [3:0]
See the Intelligent Platform Management
Interface Specification, Version 2.0, Table
42-3 for the event.
The BIOS sends this to the BMC:
Bit[7:6] = 10b - ED2 contains OEM value
Bit[5:4] = 00b - ED3 unspecified
Bit[3:0] - Supported Sensor Offsets
 0x0 - Correctable Memory Error
Logging Disabled
15 Event Data 2
(ED2)
Bit [7:0]
 OEM value or unspecified
The BIOS sends this to the BMC:
 Memory module/device identification
 Bit [7:6] - Index into SMBIOS Type 16
entry
 This shall be the zero-based memory
riser board number.
