Intel S7000FC4UR Technical Product Specification

Intel® Server System S7000FC4UR TPS BIOS Initialization
Revision 1.0
141
14.3 I/O Subsystem
14.3.1 I/O Subsystem Specification Compliance
 PCI Express Base Specification, Revision 1.1.
 PCI Local Bus Specification, Revision 2.3, PCI Special Interest Group (PCI-SIG).
 PCI-X Express Specification, Revision 2.0.
 PCI to PCI Bridge Architecture Specification, Revision 1.2, PCI Special Interest Group
(PCI-SIG)
 Universal Serial Bus v1.1 Specification and Universal Serial Bus Revision 2.0
Specification
 Serial ATA Revision 2.5 Specification, Serial ATA International Organization (SATA-IO)
 Intel Low Pin Count Interface Specification, Revision 1.1. Intel Corporation.
14.3.1.1 API Specification Compliance
 BIOS Boot Specification Version 1.01. Compaq Computer Corporation, Phoenix
Technologies Ltd., Intel Corporation. 1996]
 PCI BIOS Specification, Revision 2.1, PCI Special Interest Group (PCI-SIG)
 Plug and Play BIOS Specification, Revision 1.0a, Relevant portions of the Initial Program
Load Device (IPLD) sections only
14.3.2 Crystal Beach Technology
The Crystal Beach technology is a component of Intel
®
I/O Acceleration Technology (Intel
®
I/OAT) as described in Section 20.1. The Crystal Beach technology offers higher network
performance. In addition, it accelerates TCP/IP Offload Engine (TOE) performance.
The chipset and server hardware support Crystal Beach technology. Support is provided by
dedicated Direct Memory Access (DMA) engines on two of the PCI Express* ports.
These ports are connected to the onboard LAN controllers (Intel
®
82563EB and Intel
®
82575EB). The BIOS enables Crystal Beach technology by default.
14.3.3 Peripheral Component Interconnect (PCI) Bus
Table 36. Supported On-board PCI Devices
Bus PCI Device Comments
PCI 32-bit Onboard ATI* RN50 Video
PCI Express* x4 Onboard Intel
®
Gigabit Ethernet Intel
®
82563EB
PCI Express* x4 Dedicated Slot I/O riser board Supports Intel
®
82575EB Gigabit Ethernet
device
PCI Express* x4 Dedicated Slot SAS riser board Supports LSI* 1078 SAS Controller
PCI Express* x8 Slot 1 Hot-plug Capable
