BIOS User Interface ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
182
15.2.3.5.1 Console Redirection Screen
The Console Redirection screen provides configuration options for console redirection and
associated connectivity options.
From the Main screen select Server Management | Console Redirection to access this screen.
Server
Management
Console Redirection
Console Redirection Disabled / Serial Port A / Serial Port B
Flow Control
None / RTS/CTS
Baud Rate
9.6k / 19.2k / 38.4k / 57.6k / 115.2k
Terminal Type
PC-ANSI / VT100 / VT100+ / VT-UTF8
Legacy OS Redirection
Disabled / Enabled
Figure 59. Setup Utility — Console Redirection Screen Display
Table 57. Setup Utility — Console Redirection Configuration Fields
Setup Item Options Help Text Comments
Console Redirection
Disabled
Serial Port A
Serial Port B
Console redirection allows a serial
port to be used for server
management tasks.
[Disabled] – No console redirection
[Serial Port A] – Configure serial
port A for console redirection.
[Serial Port B] – Configure serial
port B for console redirection.
Flow Control
None
RTS/CTS
Flow control is the handshake
protocol.
Setting must match the remote
terminal application.
[None] – Configure for no flow
control.
[RTS/CTS] – Configure for
hardware flow control.
Baud Rate 9.6K
19.2K
38.4K
57.6K
115.2K
Serial port transmission speed:
Setting must match the remote
terminal application.
