Intel S7000FC4UR Technical Product Specification

Intel® Server System S7000FC4UR TPS BIOS User Interface
Revision 1.0
177
15.2.3.3.8 System Acoustic and Performance Configuration
The System Acoustic and Performance Configuration screen provides configuration options for
system thermal characteristics and behavior.
From the Main screen select Advanced | System Acoustic and Performance Configuration to
access this screen.
Advanced
System Acoustic and Performance Configuration
Throttling Mode Closed Loop / Open Loop
Figure 56. Setup Utility — System Acoustic and Performance Configuration Screen Display
Table 54. Setup Utility — System Acoustic and Performance Configuration Screen Fields
Setup Item Options Help Text Comments
Throttling Mode
Closed Loop
Open Loop
Open Loop does not rely on a
thermal sensor on the board and
sets up a static level which
equates to a fixed bandwidth.
Closed Loop will allow the system
to achieve higher performance by
monitoring system temps and
adjusting bandwidth.
Closed Loop is CLTT mode,
Open Loop is OLTT mode.
15.2.3.4 Security Screen
The Security screen provides configuration options for BIOS Security features. This screen
allows the user to set administrative and/or user passwords and to lockout front panel buttons
so they cannot be used.
From the Main screen select Security to access this screen.
