3.2.4 Sensor Data Record SDR (SDR) Repository
The BMC implements a logical Sensor Data Record (SDR) repository device. The SDR
repository is accessible via all communication transports, even while the system is powered off.
3.2.5 Field Replaceable Unit (FRU) Inventory Devices
The BMC implements the interface for logical FRU inventory devices. This functionality provides
commands used for accessing and managing FRU inventory information. These commands can
be delivered via all interfaces.
The BMC provides FRU command access to its own FRU device, as well as to the FRU devices
throughout the system. The FRU device ID mappings are shown in Table 9 and SMBus
connectivity shown in Figure 9.
The BMC controls the mapping of the FRU device ID to the physical device. Per the IPMI
specification, FRU device 0 is always located on the main board. All Intel-designed server
boards maintain onboard non-volatile storage to hold the FRU data.
Table 9. FRU Device Location and Size
FRU Device
ID
SMBus Bus
(* = CLK/DAT)
SMBus
Address
Device
Read
Only
Size
(bytes)
0 SMB_BB_SENSOR_3V3SB_* 0xA0 Main board RW 8K
1 SMB_SYS_BARD_* 0xA6 Front panel board RW 256
2 SMB_SENSOR_SEG2_3V3SB_* 0xA8 I/O riser RW 256
None SMB_IPMB_* None
Intel
®
Remote
Management Module 2
(Not supported)
N/A None
3 SMB_SYS_PWR_* 0xAA Power distribution board RW 256
4 SMB_SYS_PWR_* 0xAC Power Supply Unit 1 RO 256
5 SMB_SYS_PWR_* 0xAE Power Supply Unit 2 RO 256
6 SMB_SAS_3V3SB_* 0xA8 SAS riser RW 256
VSC410 SMB_IPMB_5VSB_* 0xAC SAS backplane RW 8K
7 SMB_MEM_3V3_* 0xA4 Memory Riser A RW 256
8 SMB_MEM_3V3_* 0xA6 Memory Riser B RW 256
9 SMB_MEM_3V3_* 0xA2 Memory Riser C RW 256
10 SMB_MEM_3V3_* 0xA0 Memory Riser D RW 256
