Intel S7000FC4UR Technical Product Specification

BIOS Role in Server Management ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
218
Offset Name Length Value Description
0Ah Data Width Word 64 FBDIMM data width (in bit units).
0Ch Size Word Varies The size of the memory device
Granularity depends on most-significant bit (bit15). For this
BIOS, Bit15 = 1 and the size of the memory device is
indicated in MB units.
If no FBDIMM is installed in the socket, this field should be
0.
0Eh Form Factor Byte 09h Form factor = DIMM
0Fh Device Set Byte Varies Identifies when the memory device is one of a set of
memory devices that must be populated with all devices of
the same type and size, and the set to which this device
belongs. A value of 0 indicates that the device is not part of
a set; a value of FFh indicates that the attribute is unknown.
The device sets are based on the lock-stepped operation
concept. In other words, lock-stepped FBDIMM pairs belong
to the same Device Set value (e.g. Memory Riser Board A,
DIMM_1 and Memory Riser Board B, DIMM_1 should have
matching device set value).
Note: A device set number must be unique within the
context of the memory array containing this memory device.
10h Device Locator Byte String The string number of the string that identifies the server
board silk screen label for the socket or board position
where the memory device is located. The string should be in
the format indicated by the following example:
Memory Riser Board A, DIMM_1
11h Bank Locator Byte NULL Memory bank concept is not supported
12h Memory Type Byte 13h Memory Device Type = DDR2.
13h Type Detail Word 0080h Type Detail:
Bit 7 = 1 (Synchronous)
15h Speed Word Varies Identifies the frequency:
215h = 533Mhz
29Bh = 667MHz
17h Manufacturer Byte String The string number manufacturer of this memory device.
18h Serial Number Byte String The string number for the serial number of this memory
device. This value is set by the manufacturer and normally
not changeable.
191h Asset Tag Byte String The string number for the asset tag of this device.
1Ah Part Number Byte String The string number for the part number of this memory
device. This value is set by the manufacturer and normally
not changeable.
18.5.3.15 Type 24 Structure — Hardware Security
The SMBIOS Type 24 structure describes the current states of the password and front panel
security features.
18.5.3.16 Type 32 Structure — System Boot Information
The SMBIOS Type 32 structure is utilized by the client's Pre-eXecution Environment (PXE) to
identify the reason why the PXE was initiated.
