Intel S7000FC4UR Technical Product Specification

Intel® Server System S7000FC4UR TPS BIOS Error Handling
Revision 1.0
231
Table 85. SEL Entry Format — Memory Sensor Type Examples
Error Type Event Data 1 Event Data 2 Event Data 3
Correctable ECC Memory Error
Memory Riser Board A, FBDIMM 6
0x20 0xFF 0x06
Bit [7:6] = 00
Bit [5:0] = 06
Uncorrectable ECC Memory Error
Memory Riser Board B, FBDIMM 5
0x21 0xFF 0x45
Bits [7:6] = 01
Bits [5:0] = 05
19.2.5 IPMI Sensor Type Events — System Firmware Progress
The BIOS is responsible for logging SEL entries for BIOS POST errors using the IPMI System
Firmware Progress sensor type. BIOS only supports the following sensor offset for this sensor
type:
 Sensor Offset 00h — System Firmware Error (POST Error)
See the Intelligent Platform Management Interface Specification, Version 2.0, Intel Corporation
Table 42-3 for the following implementation details:
Table 86. SEL Entry Format — System Firmware Progress Sensor Type
Byte Field IPMI Description BIOS Implementation
11 Sensor Type See the Intelligent Platform
Management Interface Specification,
Version 2.0, Table 42-3 for allowable
values.
The BIOS sends this to the BMC:
 0x0F = System Firmware Progress
12 Sensor
Number
Number of sensor that generated this
event.
The BIOS sends this to the BMC:
0x06 = POST Error (BIOS)
14 Event Data 1
(ED1)
Bit[7:6]
 00b = ED2 unspecified
 10b = ED2 contains OEM value
Bit[5:4]
 00b = ED3 unspecified
 10b = ED3 contains OEM value
(The BIOS does not use
encodings 01b or 11b for errors
discussed in this document.).
Bit [3:0]
See the Intelligent Platform
Management Interface Specification,
Version 2.0, Table 42-3 for the event.
The BIOS sends this to the BMC:
 Bit[7:6] = 10b - ED2 contains OEM value
 Bit[5:4] = 10b - ED3 contains OEM value
 Bit[3:0] - Supported Sensor Offsets
0x0 — System Firmware Error (POST
Error)
15 Event Data 2
(ED2)
Bit [7:0]
 OEM value or unspecified
The BIOS sends this to the BMC:
 Bit[7:0] - Least Significant Byte of the 16-
bit POST error code
16 Event Data 3
(ED3)
Bit [7:0]
 OEM value or unspecified
The BIOS sends this to the BMC:
 Bit[7:0] - Most Significant Byte of the 16-
bit POST error code
