Intel® Server System S7000FC4UR TPS BIOS Initialization
Revision 1.0
113
memory.
The BIOS automatically disables any FBDIMM that fails to conform to the rules during the POST
memory initialization.
Figure 34. Memory Population for Single-Channel with Minimal Upgrade
This configuration is a minimal system memory configuration, provides the lowest performance
and is a fail-safe mode.
Intel® Chipset
Memory Controller Hub
Branch 0
Channel 0 Channel 1
Branch 1
Channel 2 Channel 3
DIMM 1
DIMM 2
DIMM 3
DIMM 4
DIMM 5
DIMM 6
DIMM 8
Memory
Rise
r
A
DIMM 7
