Intel S7000FC4UR Technical Product Specification

Intel® Server System S7000FC4UR TPS Memory Riser
Revision 1.0
53
4.1.5 Memory Riser LEDs
The following table describes all the LEDs on the memory riser.
Table 13. Memory Riser LED Descriptions
Name Color Description
FRU pwr good Green Memory Riser Power is good
01 LED Amber DIMM1 has had an error and needs to be replaced
02 LED Amber DIMM2 has had an error and needs to be replaced
03 LED Amber DIMM3 has had an error and needs to be replaced
04 LED Amber DIMM4 has had an error and needs to be replaced
05 LED Amber DIMM5 has had an error and needs to be replaced
06 LED Amber DIMM6 has had an error and needs to be replaced
07 LED Amber DIMM7 has had an error and needs to be replaced
08 LED Amber DIMM8 has had an error and needs to be replaced
4.1.6 Power Rails
The main board supplies 12V, 5V, 3.3V, and 3.3V_stby power to the memory riser. The Memory
Riser has on-board regulators to generate 1.5V, 1.8V and 0.9V. The FBD AMB requires 1.5V,
the FBD AMB and DDR2 DRAM require 1.8V, and the DDR2 termination requires 0.9V. The
DIMM EEPROM and AMB SPD Bus require 3.3V. DIMM LEDs and control circuits require
3.3V_stby.
