HSC IPMB Application and Sensors Intel® Server System S7000FC4UR
Revision 1.0
Intel order number E18291-001
308
Sensor Name Sensor # Sensor Type
(Hex)
Event / Reading
Type Code
Event Data Re-arm Event / Threshold
Trigger
Drive Slot 4
Status
06h
3 Drive Slot
(0Dh)
6Fh Status auto Device
Rebuilding.
Device Faulty
Drive Slot 5
Status
07h
3 Drive Slot
(0Dh)
6Fh Status auto Device
Rebuilding.
Device Faulty
Drive Slot 6
Status
08h
3 Drive Slot
(0Dh)
6Fh Status auto Device
Rebuilding.
Device Faulty
Drive Slot 7
Status
09h
3 Drive Slot
(0Dh)
6Fh Status auto Device
Rebuilding.
Device Faulty
Drive Slot 0
Presence
0Ah Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 1
Presence
0Bh Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 2
Presence
0Ch Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 3
Presence
0Dh Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 4
Presence
0Eh
3 Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 5
Presence
0Fh
3 Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 6
Presence
10h
3 Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Drive Slot 7
Presence
11h
3 Drive Slot
(0Dh)
08h
Presence
2 auto dev. remove,
dev. Inserted
Notes:
1. Event messages are not generated for this sensor.
2. See Table 111.
3. Only available when HSC is in eight-disk mode.
