Intel S7000FC4UR Technical Product Specification

Intel® Server System S7000FC4UR TPS BIOS User Interface
Revision 1.0
175
Setup Item Options Help Text Comments
Onboard NIC 1 ROM
Enabled
Disabled
Load the embedded option
ROM for the onboard
network controller.
Warning: If [Disabled] is
selected, NIC1 can not be
used to boot or wake the
system.
This corresponds to the main
board Intel
®
82563EB Ethernet
device.
Onboard NIC 2 ROM
Enabled
Disabled
Load the embedded option
ROM for the onboard
network controller.
Warning: If [Disabled] is
selected NIC2 can not be
used to boot or wake the
system.
This corresponds to the main
board Intel
®
82563EB Ethernet
device.
Onboard NIC iSCSI
ROM
Enabled
Disabled
Load the embedded
Internet SCSI option ROM
for the onboard network
controller.
This corresponds to the main
board Intel 82563EB Ethernet
device.
Onboard NIC1 MAC
Address
<MAC Address>
Information only
This corresponds to the main
board Intel 82563EB Ethernet
device.
12 hex digits of the MAC
address.
Onboard NIC2 MAC
Address
<MAC Address>
Information only
This corresponds to the main
board Intel 82563EB Ethernet
device.
12 hex digits of the MAC
address.
I/O Riser Board NIC
ROM
Enabled
Disabled
Load the embedded option
ROM for the I/O Riser
Board network controllers.
Warning: If [Disabled] is
selected, the I/O Riser
Board NIC1 and NIC2 can
not be used to boot or
wake the system.
This corresponds to the Intel
I/O riser board Intel 82575EB
Ethernet device.
This menu item should be
suppressed if the I/O riser
board is not installed.
I/O Riser Board NIC1
Enabled
Disabled
Enables or disables the I/O
Riser Board network
controller.
This corresponds to the Intel
I/O riser board Intel 82575EB
Ethernet device.
This menu item should be
suppressed if the I/O riser
board is not installed.
If the user selects disabled, the
BIOS hides the PCI
configuration space for this
device and the device is
disabled.
