Intel® Server System S7000FC4UR TPS BIOS User Interface
Revision 1.0
171
<Mass Storage
Device Information>
Auto
Floppy
Forced
FDD
Hard Disk
CD-ROM
[Auto] – USB devices
less than 530 MB will be
emulated as floppy.
[Forced FDD] – HDD
formatted drive will be
emulated as FDD (e.g.
ZIP drive).
A separate line is displayed for each USB mass
storage emulation device detected.
This screen can show a maximum of eight devices.
If more than eight devices are installed, the ‘USB
Devices Enabled’ shows the correct count, but only
the first eight devices can be displayed here.
Setting the device to a specific setting assumes
that your device is formatted correctly to operate
as the choosen device, else the boot from that
device fails:
[Floppy] attempts to boot the device as a floppy
drive.
[Forced FDD] emulates a FDD boot when device is
formatted as a HDD. This option works only for
drives formatted with FAT12, FAT16 or FAT32,
and have a single partition on the device.
[Hard Disk] boots as a hard disk, This option works
only for drives formatted with FAT12, FAT16 or
FAT32,
[CD-ROM] boots as specified by the "El Torito"
Bootable CD-ROM Format Specification Version 1.
Once one of these settings are chosen, the system
remembers that setting even when the device is
removed and a different device is inserted in its
place. The user must reset this option to Auto if
they wish the device to be auto detected.
USB 2.0 Controller Enabled
Disabled
Onboard USB ports will
be enabled to support
USB 2.0 mode.
Contact your OS vendor
regarding OS support of
this feature.
