Intel® Server System S7000FC4UR TPS BIOS Role in Server Management
Revision 1.0
213
Offset Name Length Value Description
Section 3.3.5.2 for values.
07h Processor
Manufacturer
Byte String Number of null terminated string. String
contains “Intel Corporation”.
08h Processor ID QWord Varies Contains the results of the CPUID
instruction with EAX = 1 as follows:
Offset 08h-0Bh: EAX
Offset 0Ch-0Fh: EDX
10h Processor
Version
Byte String Number of Null terminated string that
describes the processor. This string is
returned from the processor.
11h Voltage Byte Varies Bit 7 - 1
Bits [6:0]
Current processor voltage * 10 - 1.8V
= 92h
12h External Clock Byte Varies External clock speed in MHz.
14h Max Speed Word Varies Maximum internal processor speed in MHz.
16h Current Speed Word Varies Current internal processor speed in MHz.
18h Status Word Varies Bit 7
0 = Reserved
Bit 6
0 = Socket unpopulated
1 = Socket populated
Bits 5:3
0 = Reserved
Bits 2:0
0h = Unknown
1h = CPU enabled
2h = CPU disabled by user
3h = CPU disabled by BIOS
4h = CPU idle, waiting to be enabled
5h, 6h = Reserved
7h = Other
19h Processor
Upgrade
Byte 04h 04h - ZIFF socket.
1Ah L1 Cache
Handle
Word Varies Handle of the cache information structure
for L1 cache for this processor. Set to
0FFFFh if the cache information structure is
not supported.
1Ch L2 Cache
Handle
Word Varies Handle of the cache information structure
for L2 cache for this processor. Set to
0FFFFh if cache information structure is not
supported.
1Eh L3 Cache
Handle
Word Varies Handle of cache information structure for
L3 cache for this processor. Set to 0FFFFh
if cache information structure is not
supported.
20h Serial Number Byte String String number for the serial number of this
processor. This value is set by the
manufacturer and normally not changeable.
21h Asset Tag Byte String String number for the asset tag of this
processor.
