Intel S7000FC4UR Technical Product Specification

Intel® Server System S7000FC4UR TPS Sensors
Revision 1.0
297
Sensor Name
3
Sensor # Sensor Type Event /
Reading Type
Event Offset
Triggers
Contrib. To
System Status
Assert /
De-assert
Readable
Value /
Offsets
Event
Data
Rearm Stand-
by
Config error Fatal
Presence OK
6Fh
Disabled Degraded
CPU Missing 94h Processor
07h
Generic
03h
01h –- State
asserted
Fatal As and
De
– R, T _ X
CPU Throttled 95h Processor
07h
Generic
03h
01h –- State
asserted
Fatal As and
De
– R, T A –
P1 Therm Margin 98h Temperature
01h
Threshold
01h
– – – Analog – – –
P2 Therm Margin 99h Temperature
01h
Threshold
01h
– – – Analog – – –
P3 Therm Margin 9Ah Temperature
01h
Threshold
01h
– – – Analog – – –
P4 Therm Margin 9Bh Temperature
01h
Threshold
01h
– – – Analog – – –
Bus correctable
error
Degraded – PCI-Express Link
Sensors
9Eh - AFh Critical
Interrupt
13F
Sensor
Specific
6Fh
Bus uncorrectable
error
Non-fatal
As – See the
BIOS
EPS
A
P1 Therm Ctrl % B0h Temperature
01h
Threshold
01h
[u] [c,nc] Non-fatal As and
De
Analog Trig
Offset
A –
P2 Therm Ctrl % B1h Temperature
01h
Threshold
01h
[u] [c,nc] Non-fatal As and
De
Analog Trig
Offset
A –
P3 Therm Ctrl % B2h Temperature
01h
Threshold
01h
[u] [c,nc] Non-fatal As and
De
Analog Trig
Offset
A –
P4 Therm Ctrl % B3h Temperature
01h
Threshold
01h
[u] [c,nc] Non-fatal As and
De
Analog Trig
Offset
A –
Proc 1 VRD Hot B8h Temperature
01h
Digital
Discrete
05h
01h – Limit
exceeded
Non-fatal As and
De
– Trig
Offset
M –
