• Baud Rate
• Parity
• Data Bits
• Stop Bits
Please refer to your CC generator users guide for recommended settings. As an example, Serial
settings for EEG are 1200 baud, 7 data bits, Odd parity and 1 stop bit.
Advance Settings
Advanced settings can be used in conjunction with any applicable CC encoders
EEG and Link CC Encoders
The settings in the advanced tab can be used to
determine the number of characters output and
therefore determine line length of the display
Extended character enables the display of special
characters
Additional output formats can be selected using the
Encoding pull down
Line termination options can be selected in the Line
Terminator pull down
