Johnson Controls CK721-A User Manual

Table 3-6: S300-RDR2 Power Consumption
S300-RDR2
5VDC
Ty
pical
(mA)
5VDC
Surge
(mA)
12VDC
Typical
(mA)
12VDC
Surge
(mA)
Wattage
(W)
Basic Board 150 300 20 45
Door Input (Secure) 20 200 0 0
Aux Input (Door
Unlock)
20 20 120 120
Lamp Warmer 0 0 160 160
Worst Case 190 520 300 325 4.55
* Typical 1 Door
(L
ed Indicators)
170 410 140 165
* Typical 2 Door
(L
ed Indicators)
190 520 240 265 2.63
* Each reader Interface provides +5VDC, +12VDC, SHUNT Output, RED Output, GREEN
Outpu
t. The current loading on these outputs must be derived from the reader manufacturers
data sheet and added to the total load. Note +5VDC is current limited to operate Cardkey
Readers (20mA).
Table 3-7: S300-I16 Power Consumption
S300-I16
5VDC
Ty
pical
(mA)
5VDC
Surge
(mA)
12VDC
Typical
(mA)
12VDC
Surge
(mA)
Wattage
(W)
Basic Board 150 200 3 3
Inputs
(16 Secure State)
80 80 0 0
Worst Case 230 280 3 3 1.19
Typical (4 Alarms) 170 170 N/A N/A
Typical (8 Alarms) 190 190 3 3
Typical (12 Alarms) 210 210 3 3
Typical (16 Alarms) 230 230 3 3
S300 Expansion Enclosures CK721-A Installation and Operation
3-20 24-10349-8 Rev. B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
