Table 3-8: S300-IO8 Power Consumption
S300-IO8
5VDC
Ty
pical
(mA)
5VDC
Surge
(mA)
12VDC
Typical
(mA)
12VDC
Surge
(mA)
Wattage
(W)
Basic Board 150 200 3 3
Inputs
(8 Secure State)
40 40 3 3
Outputs
(8 Set State)
24 24 200 200
Worst Case 214 264 206 206 3.54
Typical
(8 Alarms Secure)
170 170 3 3
Add for Each
Active Out
put
3 3 25 25
Table 3-9: S300-SIO8 Power Consumption
S300-SIO8
5VDC
Typ
ical
(mA)
5VDC
Surge
(mA)
12VDC
Typical
(mA)
12VDC
Surge
(mA)
Wattage
(W)
Basic Board 150 200 3 3
Inputs
8 Secure State)
200 200 3 3
Inputs
(8 Short State)
400 400 3 3
Outputs
(8 Set State)
24 24 200 200
Worst Case 574 624 206 206 5.34
Typical
(8 Alarms Secure)
350 170 3 3
Add for Each Active
Output
3 3 25 25
CK721-A Installation and Operation S300 Expansion Enclosures
24-10349-8 Rev. B 3-21
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
In addition to total power consumption, the total number of connections should be
considered. The interconnect mechanism within the S300 expansion enclosure
requires looping a 5-conductor cable between modules. The voltage drop across this
cable network can affect the operation of an enclosure sub-system. To insure proper
operation, measure the +5VDC at each module on the 5-wire interconnect network.
The working range for +5V should be between +5.20 to +4.85. If a voltage drop,
between modules, is greater than 0.05VDC, the quality of the interconnect cables
should be checked.
