Krone Comprima F 155 XC User Manual

Operation
168
Pos: 48.99.50 /Ü berschriften/Ü berschriften 3/A- E/D/De hnung der eingel egten Folie prüf en @ 351\mo d_143686774526 2_78.docx @ 2 630477 @ 3 @ 1
11.19.7 Checking the Stretching of the Inserted Film
Pos: 48.99.51 / BA/Bedienung /R undballenpresse/ Folienbind ung/Dehnung d er eingelegten Folie prüfen_Einleit ung @ 489 \mod_1484654 869728_78.doc x @ 3289405 @ @ 1
The round bales must be tied with the suitable film stretch level. KRONE recommends
prestretching of between 5–15%. Whether prestretching of between 5–15% has been achieved
can be checked as follows.
Pos: 48.99.52 / BA/Bedienung /R undballenpresse/ Folienbind ung/Dehnung d er eingelegten Folie prüfen_Bild @ 475\m od_147308257793 3_78.docx @ 3210066 @ @ 1
COM00405_1
X
1
2
Fig.
139
Pos: 48.99.53 / BA/Bedienung /R undballenpresse/ Folienbind ungDehnung der eing elegten Foli e prüfen_Text -vorauss_BA _Comprima F V_+X-treme @ 41 6\mod_1453211 037940_78.d ocx @ 291939 6 @ @ 1
Prerequisites:
– A round bale is pressed with film tying and put down on the field.
– The machine is shut down and safeguarded, refer to chapter Safety, Safety Routines,
“Shutting Down and Safeguarding the Machine”.
Pos: 48.99.54 / Layout Module /----------------Leerzeile-------------------- @ 240\mod_139514735702 7_0.docx @ 18 90988 @ @ 1
Pos: 48.99.55 / BA/Bedienung /R undballenpresse/ Folienbind ung/Dehnung d er eingelegten Folie prüfen_Text _BA_alle Co mprima @ 513\ mod_150339 6553078_78.doc x @ 3529450 @ @ 1
• With an overhead marker, draw two horizontal lines (1) on the film with a distance
dimension of X=100 mm.
• Cut out the section (2) around the two lines you have drawn. Make sure to cut out all film
layers.
• Allow all film layers of the cut-out section (2) to rest for at least 3 minutes.
• Measure the distance dimension X between the two lines you have drawn (1).
Pos: 48.99.56 / BA/Bedienung /R undballenpresse/ Folienbind ung/Dehnung d er eingelegten F olie prüfen_Ta belle_BA_alle Co mprima @ 4 90\mod_148516 6600817_78.d ocx @ 329107 1 @ @ 1
If the distance X is between 86 and 95 mm, prestretching has been set correctly.
Measured value X
Prestretching
Valuation
< 86 mm
> 15%
Prestretching is too strong. Reduce the
brake force at the film brake, see chapter
Settings – "Setting the film brake".
86 mm
15%
Correct
95 mm
5%
Correct
> 95 mm
< 5%
Prestretching is too weak. Increase the
brake force at the film brake, see chapter
Settings – "Setting the film brake".
Pos: 48.99.57 / BA/Info-Center /ALLE Terminals i n einem - ISO BUS, Delta, BET A II (ab BJ 1 5/16)/ALLE Ter minals/Rundball enpressen/Me nü 1-1_1 Anza hl Folienlagen _Hinweis KRON E Empfehlung_ ALLE Terminals _Comprima @ 489\mod_14 84551566948 _78.docx @ 32 88462 @ @ 1
Note
KRONE recommends 3.5 – 4 film layers for optimum chamber film wrapping. The minimum
required film layers depend on the condition of the crops.
With round bales whose diameter measures more than 130 cm and/or very dry or very wet
crops, KRONE recommends at least one additional film layer.
Pos: 48.100 /Layo ut Module /---------------Seitenumbruch---------------- @ 0\mod_1196 175311226_0.d ocx @ 4165 @ @ 1
