10: Device Ports
EMG™ Edge Management Gateway User Guide 216
2. Change the following Front Relay port fields:
3. To save, click Apply.
See Events on page 354 for information on configuring events for the DIO ports.
DIO Commands
Go to DIO Commands to view CLI commands which correspond to the web page entries
described above.
State (view only) Displays the current state of the port: on or off.
Normal State Defines the typical or normal state of the DIO Input port. This setting is used
for Events.
Name
The name of the port. Valid characters are letters, numbers, dashes (-),
periods and underscores ( _ ).
State
(view only) Displays the current state of the port: on or off. The Change
State check box and Off / On selection can be used to change the state of
the port.
Normal State
Defines the typical or normal state of the Relay port. This setting is used for
Events.
Wake State
The initial state of the relay port when the console manager boots.
Latch
Controls how a relay will be turned off if it is turned on as the result of an
event trigger. If Latch is enabled, the user will need to explicitly turn off the
relay when it is turned on as a result of an event. If Latch is disabled, the
relay will automatically turn off after the trigger condition corrects itself and
is no longer active.
