3: EMG 8500 Installation
EMG™ Edge Management Gateway User Guide 38
Order Information
To view order information, part numbers and extended support options, go to https://
www.lantronix.com/products/lantronix-emg/#tab-order-now.
User Supplied Items
To complete your installation you will need the following items:
Medium size Phillips screwdriver to install the mounting brackets to the EMG unit, if applicable
One or more serial devices that require network connectivity
A serial cable for each serial device.
- For RJ45 ports, you may use a straight-through RJ45 patch cable to connect to Cisco and
Sun RJ45 serial console ports.
- For USB ports, use a cable with a USB Type A connector
- For information about Lantronix adapters, see Appendix C: Adapters and Pinouts.
An available connection to your Ethernet network and an Ethernet cable CAT5E or better
cables are recommended for 1000 Base Ethernet.
A working AC power outlet to power the unit using the included AC (90W, 100-240V, 50/60
Hz) power supply.
If the LTE cellular modem is installed, a network SIM card (and data services) from a service
provider
Customize an EMG
Build any combination up to 8 managed console ports and up to two connectivity modules by
following these steps:
1. Pick a baseline configuration:
I/O: 4 port RS-232 or 4 port USB or two 4 port RS-232 modules
Connectivity module: Zero or one cellular module
2. Add up to one I/O module and up to two connectivity modules:
I/O: 4 port RS-232 or 4 port USB
Connectivity module: cellular module, Wi-Fi module, or dialup modem
3. Protect the investment with various extended warranty and service options. Go to https://
www.lantronix.com/products/lantronix-emg/#tab-order-now to purchase extended support.
