2: Introduction
EMG™ Edge Management Gateway User Guide 29
EMG 7500 Hardware Components
Figure 2-6 EMG 7500 Unit (front side)
Figure 2-7 EMG 7500 Unit with Wi-Fi module (back side)
LEDs
Console Port
USB Port
One I/O Device
Port Module
Dual Ethernet
Port
The appearance and function of the EMG unit will depend
upon the type of I/O module installed.
Internal LTE cellular
modem
Power
inlet
Micro
SD Card
Micro
SIM Card
The appearance and function of the EMG unit will depend upon
the model variant that has been purchased. Figure 2-7 shows
an EMG 7500 unit with an internal cellular modem and a Wi-Fi
card.
