16: Application Examples
EMG™ Edge Management Gateway User Guide 361
Dial-in (Text Mode) to a Remote Device
This example shows a phone line connection to the internal modem of the EMG, and a Sun server
connected to a device port. You can configure the modem for text mode dial-in, so a remote user
can dial into the modem using a terminal emulation program and access the Sun server.
Figure 16-3 Dial-in (Text Mode) to a Remote Device
In this example, the sysadmin would:
1. Configure the device port that the modem is connected to for dial-in:
[EMG]> set deviceport port 1 modemmode text
Device Port settings successfully updated.
[EMG]> set deviceport port 1 initscript "AT&F&K3&C1&D2%C0A"
Device Port settings successfully updated.
[EMG]> set deviceport port 1 auth pap
Device Port settings successfully updated.
[EMG]> set deviceport port 1 localsecret "password"
Device Port settings successfully updated.
[EMG]> set deviceport port 1 modemstate dialin
Device Port settings successfully updated.
[EMG]>
2. Configure the device port that is connected to the console port of the Sun UNIX server:
[EMG]> set deviceport port 2 baud 57600 flowcontrol none
Device Port settings successfully updated.
3. Dial into the EMG via the modem using a terminal emulation program on a remote PC. A
command line prompt displays.
4. Log into the EMG unit.
CONNECT 57600
Welcome to the EMG
login: sysadmin
Password:
Welcome to the EMG Console Manager
Model Number: EMG851000
For a list of commands, type 'help'.
[EMG]>
