EMG™ Edge Management Gateway User Guide 53
4: EMG 7500 Installation
This chapter provides a high-level procedure for installing the EMG 7500 followed by more
detailed information about the EMG connections and power supplies.
Caution: To avoid physical and electrical hazards, please read
Appendix B: Safety Information before installing the EMG.
EMG 7500 Package Contents
The EMG 7500 package includes the following items. Verify and inspect the contents of the EMG
package using the enclosed packing slip. If any item is missing or damaged, contact your place of
purchase immediately.
Table 4-1 EMG 7500 Parts
Additional parts and accessories are available and sold separately. For details and purchasing
information, refer to the next section Order Information.
Wall mount kit
Rail mount kit
Order Information
To view order information, part numbers and extended support options, go to https://
www.lantronix.com/products/lantronix-emg/#tab-order-now.
User Supplied Items
To complete your installation you will need the following items:
Medium size Phillips screwdriver to install the mounting brackets to the EMG unit, if applicable
One or more serial devices that require network connectivity
A serial cable for each serial device.
- For RJ45 ports, you may use a straight-through RJ45 patch cable to connect to Cisco and
Sun RJ45 serial console ports.
- For USB ports, use a cable with a USB Type A connector
Name
One EMG 7500 EDGE MANAGEMENT GATEWAY
RJ45 to DB9F Adapter
RJ45 to RJ45 Cat5 Cable, 6.6 ft (2m) straight-through RJ45 patch
RJ45 Loopback Adapter
External Universal AC (90W, 100-240V, 50/60 Hz) 12VDC power supply
North American Power cord - 110V AC power cord, 8 ft (2.43m), RoHS
Note:
Power cords for international regions are available and sold separately.
EMG 7500 Quick Start Guide
