8 Basic drive functions (MCK)
8.4 Basic settings
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Short overview of machine parameters:
After the machine parameters have been entered, the inverter sends back application-relevant data
via the following display parameters:
Parameters Info Lenze setting
Value Unit
C01206/1 Mounting direction: Motor 0: Not inverted
C01202/1
iM: Nominator of gearbox factor Z2 1
C01202/2
iM: Denominator of gearbox factor Z1 1
C01206/2
Mounting direction: Position encoder 0: Not inverted
C01203/1
iG: Numerator (motor speed) 1
C01203/2
iG: Denominator (encoder speed) 1
C01201/1
Axis data: Axis cycle
Activation of the modulo measuring system
0.0000 units
C01204
Axis data: Feed constant 360.0000 units/rev.
C00011
Appl.: Reference speed 1500 rpm
Parameters Info Lenze setting
Value Unit
C01211/1 Max. traversing speed 100%_C11
• Is used for orientation when the velocity is being set in
the profile sets.
- units/s
C01205 Axis data: Position resolution
• Is needed for the incremental specification of positions.
- incr/unit
C01210/5 MCK: Positioning accuracy
• Theoretical accuracy during positioning with account
being taken of the machine data and encoder data.
- units
C00057 Maximum torque - Nm
C01213/1 MCK: Max. traversing distance - units
Greyed out = display parameter
