Lexmark T652 - High Capacity Input Tray (HCIT) Cover, Rear Removal

High capacity input tray (HCIT) cover, rear removal
1 Remove the HCIT media tray assembly. Go to “High capacity input tray (HCIT) media tray assembly
removal” on page 372.
2 Remove the four screws (A) securing the HCIT cover, rear to the drawer.
A
A
4062
Repair information
375
