Media size actuator removal
Note: Carefully remove the base machine from the input option tray assembly before proceeding.
1 Remove the 250-sheet controller card assembly. Go to “250-sheet tray controller card assembly removal”
on page 362.
2 Remove the screw (A) securing the media size actuator to the 250-sheet frame.
A
3 Remove the media size actuator.
Media tray catch spring removal
1 Remove the 250-sheet frame assembly. Go to “250-sheet tray frame assembly removal” on page 361.
2 Turn the drawer upside down to access the media tray catch spring.
