MacDon A40D - Page 221

262334 203 Revision A
1005404
A
Figure 4.146: Forming Shield
3. Remove two clevis pins (A) from the forward end of the
forming shield.
1005181
A
Figure 4.147: Forming Shield under the Windrower
4. Position forming shield (A) under the windrower frame.
MAINTENANCE AND SERVICING
