262334 214 Revision A
Figure 4.172: Driveshield
3. Open driveshield (A). For instructions, refer to 4.2 Opening/
Closing Driveshield, page 126.
Figure 4.173: Roll Alignment Cover
4. Locate roll alignment cover (A).
Figure 4.174: Roll Alignment
5. Loosen bolt (A), and rotate cover (B) to expose the
access port.
MAINTENANCE AND SERVICING
