CONTROL SYSTEM
01–40–17
01–40
FUEL INJECTION CONTROL OUTLINE
CHU014000140S18
• The fuel injection control includes the following:
— synchronized injection control, which performs fuel injection at the rotor intake stroke according to
designated timing.
— non-synchronized injection control, which performs fuel injection only when fuel injection conditions are met
regardless of rotor intake stroke.
— Fuel cut control, which temporarily stops fuel injection.
• There are primary, secondary and primary 2 (13B-MSP (High Power)) fuel injectors, and the injection timing
and injection amount varies according to the engine speed range. Due to this, the optimum amount of fuel
injection is controlled at all ranges.
End Of Sie
