HEATED OXYGEN SENSOR (HO2S) HEATER CONTROL BLOCK DIAGRAM
CHU014000140S40
• The PCM determines the engine conditions based on input signals and sends an operation signal to the front or
rear HO2S.
End Of Sie
HEATED OXYGEN SENSOR (HO2S) HEATER CONTROL OPERATION
CHU014000140S41
Operation Conditions
• The PCM operates the HO2S when the following conditions are met.
End Of Sie
A/C CUT-OFF CONTROL OUTLINE
CHU014000140S42
• The current application (energize/de-energize) to the A/C relay (magnetic clutch) is controlled according to the
engine operation conditions to prevent deterioration of engine performance, damage to the engine, and
deterioration of the A/C function.
End Of Sie
PCM
ECT SENSOR
IAT SENSOR
FRONT HO2S HEATER
BARO SENSOR
ECCENTRIC SHAFT
POSITION SENSOR
BATTERY
MAF SENSOR
REAR HO2S HEATER
IGNITION SWITCH
CHU0140S031
HO2S Activation condition Drive signal
Front
• After engine start
• After the engine has started and a fixed period
of time has elapsed (the elapsed time period
after the engine starts is determined by ECT).
• ECT is 5°C {41°F} or more.
• Battery positive voltage is 9 V or more and less
than 16 V.
• MAF sensor is normal (no DTC is stored in
PCM).
• The PCM outputs a duty signal.
• The element temperature is measured by the
impedance of the HO2S and a duty ratio is
determined.
Rear
• Starter is off
• After engine start
• After the engine has started and a fixed period
of time has elapsed (the time period after the
engine starts lenghtens if the ECT falls below
0°C {32°F}.
• ECT is 10°C {50°F} or more.
• Battery positive voltage is 9 V or more and less
than 16 V.
• Charging efficiency is the fixed value or less, or
during fuel cut.
• The PCM outputs a duty signal. However the
duty signal is either 100% or 0%.
