Mazda RX-8 2004 - Simulation Test

ON-BOARD DIAGNOSTIC
01–02–20
SIMULATION TEST
CHU010200102S06
• The simulation items are shown below.
Simulation item table
×: Applicable
—: Not applicable
End Of Sie
Item Applicable component Unit/condition
Test condition
PCM terminal
KOEO KOER
ACCS A/C relay On/Off ×× 5AA
AIP RLY AIR pump relay On/Off ×× 4O
ALTF Generator (field coil) % — × 2I
APV APV motor On/Off ×× 3G, 3J
ARPMDES Target engine speed RPM ×× —
DEI VDI solenoid valve On/Off ×× 1W
ETC_DSD Target throttle valve opening angle °××—
EVAPCP Purge solenoid valve % ×× 2P
FAN1 Cooling fan relay No.1 On/Off ×× 5X
FAN2 Cooling fan relay No.2 On/Off ×× 5AD
FP Fuel pump relay On/Off ×× 5P
FPRR Fuel pump speed control relay On/Off ×× 4M
FUELPW1 Fuel injector (FP1, RP1) % — × 2J, 2M
GENVDSD Target generator voltage V — × —
HTR12 Rear HO2S heater On/Off ×× 2A
IASV VFAD solenoid valve On/Off ×× 5Z
MOP_POS Metering oil pump — ××2V, 2W, 2Y, 2AB
PACNTV AIR solenoid valve On/Off ×× 1O
PREDELI Delivery mode On/Off ×× —
SSV SSV solenoid valve On/Off ×× 1L
test Test mode On/Off ×× —
