CONTROL SYSTEM
07–40–4
RESISTOR OPERATION
CHU074061480S05
• Changes the resistance value of the blower motor operation current based on fan switch operation to control
the airflow volume.
End Of Sie
MAGNETIC CLUTCH CONSTRUCTION
CHU074061480S06
• Engages and disengages the A/C compressor body according to control signals from the PCM. When
engaged, it transmits engine power to the A/C compressor body via the drive belt.
End Of Sie
BLOWER
MOTOR
1
4
2
3
BLOWER
RELAY
RESISTOR
FAN SWITCH
M
IG2
B+
0
A/C AMPLIFIER
CHU0740S009
MAGNETIC CLUTCH
A/C COMPRESSOR BODY
CHU0711S011
