PARKING BRAKE SYSTEM OUTLINE
CHU041201022S01
• A center lever type parking brake that can be adjusted from the vehicle interior has been adopted, improving
operability.
• Parking brake lever adjustment can easily be performed by removing the service hole cover in the rear
console, improving serviceability.
End Of Sie
PARKING BRAKE SYSTEM STRUCTURAL VIEW
CHU041201022S02
End Of Sie
SERVICE HOLE COVER
ADJUSTING NUT
PARKING BRAKE LEVER
CHU0412S001
