FRONT AXLE
03–11–1
03–11
03–11 FRONT AXLE
FRONT AXLE OUTLINE . . . . . . . . . . . . . 03–11–1 FRONT AXLE CROSS-SECTIONAL
VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03–11–1
End of Toc
FRONT AXLE OUTLINE
CHU031104000S01
• For the front axle wheel bearing, unit-design angular ball bearings with low rotational resistance have been
adopted. Due to this, driveability and serviceability have been improved.
• The wheel hub component is integrated with the ABS wheel-speed sensor, improving reliability.
End Of Sie
FRONT AXLE CROSS-SECTIONAL VIEW
CHU031104000S02
End Of Sie
ABS
WHEEL-SPEED
SENSOR
ANGULAR
BALL
BEARING
CHU0311S001
