REAR AXLE
03–12–1
03–12
03–12 REAR AXLE
REAR AXLE OUTLINE . . . . . . . . . . . . . . 03–12–1 REAR AXLE CROSS-SECTIONAL
VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03–12–1
End of Toc
REAR AXLE OUTLINE
CHU031205000S01
• As with the front axle, unit-design angular ball bearings have been adopted, improving driveability and
serviceability.
End Of Sie
REAR AXLE CROSS-SECTIONAL VIEW
CHU031205000S02
End Of Sie
ANGULAR
BALL
BEARING
CHU0312S001
