INTERIOR TRIM
09–17–1
09–17
09–17 INTERIOR TRIM
INTERIOR TRIM OUTLINE . . . . . . . . . . . 09–17–1 INTERIOR TRIM STRUCTURAL VIEW . . 09–17–1
End of Toc
INTERIOR TRIM OUTLINE
CHU091755000S01
• The center module with integrated audio and climate control units, is located at the center of the dashboard
panel. This improves functionality and gives a unified appearance.
• Various storage spaces have been added.
End Of Sie
INTERIOR TRIM STRUCTURAL VIEW
CHU091755000S02
End Of Sie
CENTER PANEL MODULE
ASHTRAY
CONSOLE
STORAGE
COMPARTMENT
STORAGE
COMPARTMENT
CUP HOLDER
STORAGE COMPARTMENT
DOOR POCKET
GLOVE COMPARTMENT
CHU0917S101
