FUEL SYSTEM
01–14–2
FUEL SYSTEM STRUCTURAL VIEW
CHU011401006S02
Engine Room Side
Fuel Tank Side
End Of Sie
QUICK RELEASE CONNECTOR
QUICK RELEASE CONNECTOR
CHECK
CONNECTOR
FUEL PUMP SPEED
CONTROL RELAY
FUEL PUMP RESISTOR
FUEL INJECTOR
(FS)
FUEL INJECTOR
(RS)
FUEL INJECTOR (FP2, RP2)
(13B-MSP (HIGH POWER))
FUEL INJECTOR
(FP1, RP1)
MAIN FUSE BLOCK
FUEL PUMP
RELAY
CHU0114S001
FUEL PUMP
UNIT
FUEL TANK
NON RETURN VALVE
CHU0114S002
