Mazda RX-8 2004 - Audio System Structural; Entertainment Outline; Audio System Block Diagram

ENTERTAINMENT
09–20–3
09–20
AUDIO SYSTEM BLOCK DIAGRAM
CHU092001066S03
BOSE Specification Vehicles
Standard specification Vehicles
End Of Sie
CENTER PANEL
MODULE
(BUILT-IN
AUDIO UNIT)
INFORMATION
DISPLAY
AUDIO
CONTROL
CIRCUIT
AUDIO
CONTROL
SWITCH
TNS SIGNAL
VEHICLE
SPEED
SIGNAL
ANTENNA
AUDIO
UNIT
BASE UNIT
UPPER
MODULE
LOWER
MODULE
MAIN
AMPLIFIER
AUDIOPILOT
MICROPHONE
FRONT DOOR
SPEAKER (RIGHT)
REAR SPEAKER
(LEFT)
REAR SPEAKER
(RIGHT)
FRONT TWEETER
(LEFT)
FRONT DOOR
SPEAKER (LEFT)
FRONT TWEETER
(RIGHT)
REAR TWEETER
(RIGHT)
REAR TWEETER
(LEFT)
CENTER
SPEAKER
FRONT DOOR
SPEAKER AMPLIFIER
CHU0920S002
CENTER PANEL
MODULE
(BUILT-IN
AUDIO UNIT)
INFORMATION
DISPLAY
AUDIO
CONTROL
CIRCUIT
AUDIO
CONTROL
SWITCH
TNS SIGNAL
VEHICLE
SPEED
SIGNAL
ANTENNA
AUDIO
UNIT
BASE UNIT
UPPER
MODULE
LOWER
MODULE
FRONT DOOR
SPEAKER (RIGHT)
REAR SPEAKER
(LEFT)
REAR SPEAKER
(RIGHT)
FRONT TWEETER
(LEFT)
FRONT DOOR
SPEAKER (LEFT)
FRONT TWEETER
(RIGHT)
CHU0920S129
